LED ENGINE & IP RATING & FINISH

LED ENGINE & IP RATING

LED Engine refers to the LED manufacturer and type. IP refers to the Ingress Protection of a luminaire. The first number indicates the level of protection the luminaire provides against the ingress of solid foreign bodies. The second number indicates the level of protection the luminaire provides against the ingress of moisture. IP20 gives protection for normal interior use. IP44 gives higher protection for areas with water such as bath and shower rooms.

BEAM ANGLE

Please choose the beam angle.

If more exact photometric details are needed please refer to the polar curves or data files.

REFLECTOR FINISH

Sometimes there is a choice of reflector finish. Please pick one.

LED LUMENS / WATTAGE

There are usually a number of lumen outputs to choose from, please specify which one you want. For CRI90, please see the PDF family datasheet. For other lumen outputs please contact us.

DRIVER

A driver is needed to operate and control every LED luminaire. They are self-contained units but are wired to the luminaire and have outputs matched to the characteristic of the LED. Its specification depends on whether dimming is required or not. There is also ADDRESSABLE, which is only relevant to DALI addressable fixtures requiring emergency and should be specified with emergency fixtures for that protocol.
